Brass Pipe & Hose Fittings
Also designated: BSP fittings · ISO 228 fittings · Pneumatic fittings · Compression fittings · Brass hose tails · Brass adaptors
General
What this product is
Brass pipe and hose fittings for water service, pneumatics and OEM manifolds. Threads are the inspection point: BSP (G) to ISO 228, DIN 259, metric, and NPT on request. We machine elbows, tees, nipples, adaptors, hose tails, reducers and drawing-controlled specials in CW617N / CW614N, nickel-plate when specified, and thread-check before packing. Importers reject lots when gauges fail — every production lot is gauged, not sampled only at the start.
Importers reject lots when threads fail gauges. We thread-check and label cartons for warehouse SKUs.
At a glance
- — BSP (G) / ISO 228 / DIN 259 / metric / NPT on request
- — Elbows, tees, nipples, adaptors, hose tails, reducers
- — Nickel plated options
- — Thread gauges on every lot
STPL · Gold Supplier 12 yrs · CW614N / EN
Technical data
Specification
- Product type
- Brass pipe, hose and pneumatic fittings — catalogue and drawing-controlled
- Thread forms
- BSPP / BSPT (G / R) to ISO 228; DIN 259; metric; NPT on request
- Typical sizes
- 1/8" to 2" BSP and equivalent metric — other sizes from drawing
- Forms
- Straight, elbow, tee, nipple, adaptor, reducer, hose tail, bulkhead, specials
- Material
- CW617N (hot-working / fittings) and CW614N (free-cutting) as the part requires
- Finish
- Natural brass or nickel plated
- Sealing
- Thread class and seat as per drawing; PTFE / O-ring not included unless specified
- Pressure duty
- Declared on the quote against size, thread and application — not a blanket bar rating
Materials
- — CW617N / EN 12165
- — CW614N / EN 12164
Finishes
- — Natural brass
- — Nickel plated
Applications
- — Pneumatics
- — Water service
- — OEM manifolds
- — Industrial assemblies
Standards
- — ISO 228 (BSP)
- — DIN 259
- — NPT on request
- — Material EN 12164 / EN 12165
- — REACH / RoHS against the lot
Inspection
- — Thread gauges (go/no-go) on production lots
- — Seat / leak-path visual
- — Plating on coated lots
- — Hex and overall dimensions
Documents with shipment
- — Commercial invoice
- — Packing list
- — Certificate of origin
- — Material note against the alloy of the lot
- — REACH / RoHS statement on request, against plating and alloy of the lot
- — ISO 9001 / 14001 / 45001 PDFs with the first RFQ reply
Standard range
Variants we quote
BSP adaptor / nipple
Male-male, male-female, reducing
Elbow / tee
Equal or reducing, BSP or metric
Hose tail
Barb × BSP for pneumatic and water hose
Compression / special
From sample or drawing
Commercial
Samples, packing, Incoterms
- Manufacturer
- Satyam Techworks Pvt. Ltd., Dared, Jamnagar — factory direct, not a trader
- Alibaba
- Gold Supplier · 12 years (since 2014)
- Samples
- First-article sample before the production lot. Typical sample 10–50 pcs.
- MOQ
- Quoted against SKU, plating and any tooling. Typical production from 500 pcs for catalogue bars; OEM inserts often 1,000+.
- Lead time
- Quoted on RFQ. Typical: samples 10–18 days after drawing freeze; production 25–40 days after sample approval.
- Incoterms 2020
- FOB Mundra / Nhava Sheva. All Incoterms 2020 accepted.
- Packing
- Poly bag / inner box / export carton. Palletised on request. Carton labels to your warehouse SKU and PO.
- Payment
- As agreed on the proforma. Standard export terms.
- Sizing
- Sorted by thread size; mixed cartons labelled per SKU
How to order this item
Send the fields below on the Export Desk RFQ. We reply within one business day with alloy, finish, first-article option and Incoterms 2020 (FOB Mundra / Nhava Sheva; all terms accepted) — as the manufacturer, not a trader.
- 01Product name as listed here (or your Alibaba / internal SKU)
- 02Drawing, STEP/PDF or approved sample
- 03Alloy if known (CW614N / CW617N / other)
- 04Finish (natural brass / nickel / tin) and any salt-spray note
- 05Annual quantity and first PO size
- 06Destination port and Incoterm
- 07Inspection standard and required documents
- 08Thread form and size (e.g. G 1/2, R 3/8, NPT 1/4)
