Brass Molding Inserts

Also designated: Brass threaded inserts · PPR brass inserts · CPVC / UPVC / PVC pipe-fitting inserts · Mould-in brass inserts

Brass mould-in inserts for PPR, CPVC, UPVC and PVC fittings and plastic housings — thread, knurl and plating to the mould drawing.

Request factory quote First-article sample

General

What this product is

Brass molding inserts are the metal thread that sits inside a plastic or PPR/CPVC fitting. Pipe-fitting and appliance OEMs specify the knurl, the thread (BSP, NPT or metric) and nickel or chrome plating. We machine CW614N inserts from the housing or fitting drawing, freeze a first article, then run counted production lots. This is the same insert family listed on our Alibaba Gold Supplier store — not a trader’s mixed carton.

Pipe-fitting and plastic-housing OEMs reject inserts when knurl OD or thread class drifts. We gauge both, plate as specified, and pack counted to the SKU.

At a glance

— Mould-in inserts for PPR / CPVC / UPVC / PVC fittings
— BSP, NPT and metric threads
— Knurl / hex OD from the mould drawing
— Natural, nickel or chrome plated

STPL · Gold Supplier 12 yrs · CW614N / EN

Technical data

Specification

Product type: Brass mould-in / heat-stake insert for plastic and PPR-family fittings
Mate: PPR, CPVC, UPVC, PVC pipe fittings and thermoplastic housings
Threads: BSP / NPT / metric — size on RFQ (typical ½″–2″ fitting inserts and M3–M12 housing inserts)
Knurl / OD: As per mould drawing or approved sample
Material: CW614N (CuZn39Pb3) / EN 12164
Finish: Natural brass, nickel or chrome — as specified

Materials

— CW614N / EN 12164

Finishes

— Natural brass
— Nickel plated
— Chrome plated

Applications

— PPR and CPVC fittings
— Plastic pipe systems
— Appliance housings
— Overmoulded connectors

Standards

— Material EN 12164
— Thread ISO 228 / NPT / metric as specified
— REACH / RoHS against the lot

Inspection

— Thread gauges
— Knurl / OD vs first article
— Plating on coated lots

Documents with shipment

— Commercial invoice
— Packing list
— Certificate of origin
— Material note against the alloy of the lot
— REACH / RoHS statement on request, against plating and alloy of the lot
— ISO 9001 / 14001 / 45001 PDFs with the first RFQ reply

Standard range

Variants we quote

PPR / CPVC fitting insert

Male or female thread, knurl for overmould

Housing mould-in insert

Metric thread, knurl OD from plastic drawing

NPT insert

US thread for export fittings

Commercial

Samples, packing, Incoterms

Manufacturer: Satyam Techworks Pvt. Ltd., Dared, Jamnagar — factory direct, not a trader
Alibaba: Gold Supplier · 12 years (since 2014)
Samples: First-article sample before the production lot. Typical sample 10–50 pcs.
MOQ: Quoted against SKU, plating and any tooling. Typical production from 500 pcs for catalogue bars; OEM inserts often 1,000+.
Lead time: Quoted on RFQ. Typical: samples 10–18 days after drawing freeze; production 25–40 days after sample approval.
Incoterms 2020: FOB Mundra / Nhava Sheva. All Incoterms 2020 accepted.
Packing: Poly bag / inner box / export carton. Palletised on request. Carton labels to your warehouse SKU and PO.
Payment: As agreed on the proforma. Standard export terms.
Count: Counted bags or trays to moulding-line SKU

How to order this item

Send the fields below on the Export Desk RFQ. We reply within one business day with alloy, finish, first-article option and Incoterms 2020 (FOB Mundra / Nhava Sheva; all terms accepted) — as the manufacturer, not a trader.
