Brass Terminal Blocks & Terminal Bars

Also designated: Terminal bars · Connector inserts · Ceramic terminal inserts · Brass electrical connectors · Brass connector studs

Brass terminal blocks, terminal bars and connector inserts for ceramic, phenolic and moulded housings — the electrical-connector family listed by OEMs and wholesalers.

Request factory quote First-article sample

General

What this product is

Brass terminal inserts and terminal bars are the current-carrying parts inside ceramic, phenolic or thermoplastic connector housings. OEMs buy them as drawing-controlled inserts (studs, barrels, multi-way bars) with defined thread, plating and press-fit or mould-in geometry. We reverse from a sample or machine from STEP/PDF, freeze a first article, then run production on the same gauges. IEC 60947-7-1 alignment is available when the housing and creepage are the buyer’s design.

Repeat OEM programmes need stable dimensions, plating adhesion and batch traceability. First-article samples, then production with the same gauges.

At a glance

— Single-way and multi-way inserts
— Mould-in, press-fit or screw-fix geometry
— Nickel plated options
— Custom from drawing or sample
— IEC 60947-7-1 alignment on request

STPL · Gold Supplier 12 yrs · CW614N / EN

Technical data

Specification

Product type: Brass terminal insert, terminal bar, connector stud or barrel
Ways: Single-way to multi-way bars as per housing
Threads: M3 / M4 / M5 / M6 and drawing threads; UNC on request
Geometry: Mould-in knurl / hex, press-fit, or screw-mounted
Housing mate: Ceramic, phenolic, PA, PBT — insert is brass only; housing is yours unless specified
Material: CW614N typical. CW508L (CuZn37) on request for specific conductivity/forming.
Finish: Natural, nickel, tin — adhesion checked on plated lots
Electrical: Current and voltage declared with the housing design; we supply the brass part to drawing

Materials

— CW614N / EN 12164
— CW508L on request

Finishes

— Natural brass
— Nickel plated
— Tin plated

Applications

— Ceramic connectors
— Industrial terminal blocks
— OEM connector assemblies
— Appliance terminals

Standards

— Material EN 12164
— IEC 60947-7-1 alignment on request
— REACH / RoHS against the lot

Inspection

— Critical dimensions vs first article
— Thread gauges
— Plating adhesion (plated lots)
— Knurl / press-fit diameter where specified

Documents with shipment

— Commercial invoice
— Packing list
— Certificate of origin
— Material note against the alloy of the lot
— REACH / RoHS statement on request, against plating and alloy of the lot
— ISO 9001 / 14001 / 45001 PDFs with the first RFQ reply

Standard range

Variants we quote

Ceramic connector insert

Stud or barrel for ceramic terminal blocks

Phenolic housing insert

Mould-in or assembled brass terminal

Multi-way terminal bar

Open bar for OEM assemblies

Connector stud

Threaded stud with shoulder / knurl as per sample

Commercial

Samples, packing, Incoterms

Manufacturer: Satyam Techworks Pvt. Ltd., Dared, Jamnagar — factory direct, not a trader
Alibaba: Gold Supplier · 12 years (since 2014)
Samples: First-article sample before the production lot. Typical sample 10–50 pcs.
MOQ: Quoted against SKU, plating and any tooling. Typical production from 500 pcs for catalogue bars; OEM inserts often 1,000+.
Lead time: Quoted on RFQ. Typical: samples 10–18 days after drawing freeze; production 25–40 days after sample approval.
Incoterms 2020: FOB Mundra / Nhava Sheva. All Incoterms 2020 accepted.
Packing: Poly bag / inner box / export carton. Palletised on request. Carton labels to your warehouse SKU and PO.
Payment: As agreed on the proforma. Standard export terms.
OEM packing: Counted bags or trays to line-side SKU; barcodes on request

How to order this item

Send the fields below on the Export Desk RFQ. We reply within one business day with alloy, finish, first-article option and Incoterms 2020 (FOB Mundra / Nhava Sheva; all terms accepted) — as the manufacturer, not a trader.
